The 16ft New High Cube Storage Container with Roll-Up Door combines a mid-size footprint with maximum vertical clearance and convenient overhead door access. Built from heavy-duty corrugated Corten steel, this one-trip unit is purpose-designed for secure, weatherproof storage with quick entry — fitting easily into a standard parking space, backyard, or tight commercial lot.
At 9’6″ tall, the high cube design provides approximately 10% more internal volume than a standard-height 16ft container, offering the headroom to stack pallets, store tall equipment, and walk in comfortably. The full-width roll-up door replaces traditional swing-out cargo doors, allowing faster loading and unloading in tight spaces where door clearance is limited.
The container features 1-1/8″ thick marine-grade plywood flooring over steel cross-members, corner castings on all corners, forklift pockets, and a fully weatherproof seal. It is ground-level accessible — no ramp required.
“Common uses include construction tool and equipment storage, retail backstock, agriculture supply storage, residential garage overflow, landscaping equipment, event and festival storage, and mobile workshop space.”
Specification
| Specification | Detail |
|---|---|
| Exterior Length | 16 ft 0 in. (4.877 m) |
| Exterior Width | 8 ft 0 in. (2.438 m) |
| Exterior Height | 9 ft 6 in. (2.896 m) |
| Interior Length | 15 ft 5 in. (4.700 m) |
| Interior Width | 7 ft 8 in. (2.340 m) |
| Interior Height | 8 ft 10 in. (2.693 m) |
| Roll-Up Door Width | 7 ft 8 in. (2.340 m) |
| Roll-Up Door Height | 7 ft 4 in. (2.235 m) |
| Interior Cubic Capacity | Approx. 1,070 cu ft (30.3 m³) |
| Interior Floor Area | Approx. 118 sq ft (11.0 m²) |
| Tare Weight | Approx. 3,500 lbs (1,588 kg) |
| Max Payload | Approx. 17,500 lbs (7,938 kg) |
| Max Gross Weight | Approx. 21,000 lbs (9,525 kg) |
| Construction | Heavy-duty corrugated Corten steel (corrosion-resistant) |
| Flooring | 1-1/8 in. (28 mm) marine-grade plywood over steel cross-members |
| Door Type | Roll-up overhead door (full-width) |
| Door Seals | Weatherproof rubber seals |
| Corner Castings | All 8 corners (top and bottom) |
| Forklift Pockets | Yes |
| Ground Level | Yes — no ramp required |
| Ventilation | Standard air vents |
| ISO Certified | Non-ISO (custom size) |
| Lockbox | Included |
| Condition | New (one-trip) |
ORDER ONLINE TODAY with transparent pricing and fast delivery. A secure, space-efficient, and easy-access storage solution.
Custom paint and branding options are available upon request.
